| Product Number |
|
| Type |
| Scale |
1/10th |
| Brushed/Brushless |
Brushless |
| Sensored/Sensorless |
Sensorless |
| Waterproof |
Waterproof |
|
| Specifications |
| Cont./Peak Current |
60A/360A |
| Input Voltage |
2-3S Lipo |
| BEC Output |
Switch Mode 6V @3A |
|
| Wires & Connectors |
| Input Wires |
Black-14AWG-150mm*1 Red-14AWG-150mm*1
|
| Output Wires |
Black-14AWG-60mm*3 |
| Input Connectors |
No |
| Output Connectors |
4.0MM Gold (female) |
|
| Fan |
| Type |
Framed |
| Size |
30x30x10mm |
| Voltage Range |
6V |
| Powered by |
BEC |
|
| ESC Programing via |
| SET Button on ESC |
Supported |
| LED Program Box |
Supported |
| LCD G2 Program Box (STOPPED) |
Supported |
| LCD PRO |
Supported |
| OTA Programmer |
Not Supported |
| WiFi Module (STOPPED) |
Not Supported |
| Program Port |
Shared with fan port |
|
| Data Recording |
| Extreme value |
Not Supported |
| Real-time Data |
Not Supported |
| Historical data (Graph) |
Not Supported |
|
| Firmware |
| Firmware Upgrade |
Not Supported |
|
| Size & Weight |
| Size |
46*36.5*34.3mm |
| Weight |
82.6g (Included wires&connectors) |
|
| Applications |
| Motors |
Sensorless / Sensored Brushless Motor (only in sensorless mode) |
| Vehicles |
1/10th On-road,Buggy,Short course truck |
| KV Rating/T Count |
2S LiPo:KV≤6000；3S LiPo:KV≤3500（3652/3660 size motor） |
|
