EzRun MAX10
Specifications
Product Name
Product Number
Type
Specifications
Wires & Connectors
Fan
ESC Programing via
Firmware
Size & Weight
Applications
Programmable Items
Specifications
Product Name
EzRun MAX10
Product Number
30102602
Type
Scale
1/10th
Brushed/Brushless
BL
Sensored/Sensorless
SL
Waterproof
Specifications
Cont./Peak Current
60A/450A
Input Voltage
2-3S LiPo/6-9 Cells NiMH
BEC Output
Switch Mode: 6V/7.4V,3A
Wires & Connectors
Input Wires
Red-14AWG-200mm*1/Black-14AWG-200mm*1
Output Wires
Black-14AWG-200mm*3
Input Connectors
No
Output Connectors
3.5 Bullet Connectors (Female)
(Note: All the wire length above is the original length not the length you see from the outside.)
Fan
Size
25.0x25.0x10.0mm
Voltage Range
5-7.4V
Powered by
BEC
ESC Programing via
SET Button on ESC
Supported
LED Program Box
Supported
LCD Program Box
Supported
WiFi Module
Supported
OTA Programmer
Supported
Program Port
PRG/Fan Port
Firmware
Firmware Upgrade
Supported
Size & Weight
Size
39.4x32.8x23.1mm (w/o Fan)
Weight
67.8g
Applications
Motors
SL BL Motors/SD BL Motors (only in SL mode)
Vehicles
1/10th Buggy, On-road, and Light-weight 2WD SCT, Truck and Monster Truck
KV Rating/T Count
2S LiPo: KV≤6000;3S LiPo: KV≤4000 (3652 Series of Motors)
Programmable Items
